Spezifikationen
Akku
840Wh battery
Dämpfer
FOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment, 210x55mm
Display
All New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized App
Extras
SWAT Internal downtube storage
Federweg Dämpfer (mm)
160
Federweg Gabel (mm)
160
Felgen
Specialized, hookless alloy, 30mm inner width, tubeless ready
Griffe
Specialized Trail Grips
Kassette/Zahnkranz
SRAM XS-1275, 12-speed, 10-52t
Kette
SRAM GX Eagle T-Type Flattop Chain, 12-speed
Kettenblätter
SRAM 34t T-Type chainring, 104 BCD, steel
Kurbel
SRAM S1000 Crankset, ISIS Interface, Integrated Guard, 55mm Chainline, 155mm
Ladegerät
Specialized 4amp charger
Lenker
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, S1-S2: 780mm width, S3-S6 800mm width
Nabe hinten
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Nabe vorne
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rahmen
All new Levo 4 M5 Alloy frame, 150mm travel,, adjustable chainstay, adjustable head tube angle, adjustable bottom bracket, internal SWAT storage 148mm spacing, 29" front wheel/27.5" rear wheel, fork travel up to 180mm
Rahmenhöhe
S5
Sattel
Bridge Comp, Hollow Cr-mo rails 155/143
Sattelstütze
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4: 170mm, S5/S6: 190mm
Schalthebel
SRAM 90 trigger, 12-speed, single click
Schaltwerk
SRAM Eagle 90 T-Type
Speichen
DT Swiss Industry
Vorbau
Alloy Trail Stem, 35mm bar bore
Akkuleistung (Wh)
840Wh
Modelljahr
2026
Laufradgröße
29''
Motor
Specialized
Rahmenform
Diamant
