Spezifikationen
Dämpfer
FOX FLOAT X NUDE EVOL Piggy Back Trunnion / SCOTT custom w. travel / geo adj., 3 modes: Climb-Ramp Control-Descend, Custom large Air volume / Comp & Reb. Adj., Travel 170-130-Climb / T205X65mm / Bearing Hardware
Extras
Syncros IS Matchbox kit / Syncros Multi-tool Matchbox 8
Federweg Dämpfer (mm)
170
Federweg Gabel (mm)
170
Felgen
Syncros Revelstoke 2.5 6 Bolt, F: 15x110mm, R: 12x148mm Boost, 30mm Tubeless ready rim 28Hr, Syncros Axle w/Removable Lever with Tool
Gewicht in kg
16,4
Griffe
Syncros Endurance lock-on grips
Innenlager
SRAM DUB PF integrated / shell 41x92mm
Kassette/Zahnkranz
SRAM NX / PG1210 / 11-50 T
Kette
SRAM CN SX Eagle
Kurbel
SRAM X1 1000 Eagle DUB Boost, 32T / Chainline 55mm
Laufradsatz
Syncros Revelstoke 2.5 6 Bolt, F: 15x110mm, R: 12x148mm Boost, 30mm Tubeless ready rim 28Hr, Syncros Axle w/Removable Lever with Tool
Lenker
Syncros Hixon 2.0 Alloy 6061 D.B., Size S & M 12mm Rise / Size L & XL 20mm Rise / back sweep 8° / 780mm
Rahmen
Ransom Carbon HMF Mainframe with Alloy 6061 Swingarm, Integrated Suspension Technology, 6 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline / MX Ready
Rahmenhöhe
L
Reifen
Maxxis Assegai / 2.5" / 60TPI Foldable / EXO+ / TR / 3C Maxx Gripp
Sattel
Syncros Tofino 2.0, Crmo Rails
Sattelstütze
Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm, S size 140mm / M size 180mm / L & XL size 210mm
Schalthebel
SRAM SX Eagle Trigger
Schaltwerk
SRAM NX Eagle 12 Speed
Steuersatz
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Vorbau
Syncros AM 2.0, Syncros Cable Integration System, 4° rise / 6061 Alloy / 31.8mm / 40mm
Zulässiges Gesamtgewicht in kg
128
Beleuchtung
Nein
Gabel
Federgabel
Gepäckträger
Nein
Modelljahr
2025
Laufradgröße
29''
Rahmenform
Diamant
Rahmenmaterial
Carbon
Schaltung
Kettenschaltung
Schutzbleche
Ja
