Spezifikationen
Federweg Gabel (mm)
100
Felgen
Syncros X-30SE / 32H / 30mm, Tubeless ready
Gewicht in kg
11,7
Griffe
Syncros Performance XC lock-on grips
Innenlager
Shimano BB-MT500 / shell 41x92mm
Kassette/Zahnkranz
Shimano Deore CS-M6100-12 / 10-51 T
Kette
Shimano CN-M6100
Kurbel
Shimano SLX FC-M7120-1 / Hollowtech 2, 55mm CL / 32T
Lenker
Syncros Fraser 2.0 XC Alloy 6061 D.B., Flat Bar / 8° / 740mm
Nabe hinten
Formula CL-148M / 12x148mm / Micro Spline
Nabe vorne
Formula CL-811 / 15x110mm
Rahmen
Scale Carbon HMF, Adjustable head angle / Syncros Cable Integration System, Advanced Shock & Standing Damping System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
Rahmenhöhe
XL
Reifen
Schwalbe Racing Ray 29x2.35", Performance Folding / TLE Tubeless ready / Addix
Sattel
Syncros Belcarra Regular 2.0, CrMo rails
Sattelstütze
Syncros Duncan 2.0, 31.6x400mm
Schalthebel
Shimano Deore SL-M6100-R / Rapidfire Plus
Schaltwerk
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
Speichen
Stainless Black 15G / 1.8mm
Steuersatz
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Vorbau
Syncros DC 3.0, Syncros Cable Integration System, 0° rise / 6061 Alloy / 31.8mm / 1 1/8"
Zulässiges Gesamtgewicht in kg
128
Beleuchtung
Nein
Gabel
Federgabel
Gepäckträger
Nein
Modelljahr
2025
Laufradgröße
29''
Rahmenform
Diamant
Rahmenmaterial
Carbon
Schaltung
Kettenschaltung
Schutzbleche
Nein
