Spezifikationen
Akku
Bosch PowerTube 800
Dämpfer
Fox Float Performance, 230x60mm (27.5: 210x55mm), Adjustable LSR w/ 2-Pos. Lever
Display
Bosch Kiox 400C
Gewicht in kg
24,5 kg
Griffe
ACID Endure VariGrip System
Kassette/Zahnkranz
Shimano XT CS-M8200, 10-51T
Kette
Shimano CN-M8100
Kurbel
ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T
Ladegerät
Bosch 4A
Laufradsatz
Newmen Performance 30 base/strong, 28/32 Spokes, 15x110mm / 12x148mm, Tubeless Ready
Lenker
CUBE Rise Trail Bar 35 VariGrip System
Pedale
ACID PP MTB
Rahmen
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
Rahmenhöhe
M
Sattel
ACID Venec EMTB Trail 140
Sattelstütze
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Schalthebel
Shimano Deore XT SL-M8210-IR, Direct Attach, Single Click
Schaltwerk
Shimano XT RD-M8200-SGS, ShadowPlus, 12-Speed
Steuersatz
Acros AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface
Vorbau
CUBE Performance Stem E-MTB 35, FPI-Link
Zulässiges Gesamtgewicht in kg
160 kg
Akkuleistung (Wh)
800
Modelljahr
2027
Laufradgröße
29''
Motor
Bosch
Rahmenform
Diamant
